Rolling Ring Drives, Traverse Units

Rolling Ring Drives are mechanical devices that convert rotary motion into linear reciprocating motion. This motion is achieved through a series of contact points between a shaft and a set of rolling rings.

Rolling Ring Traverse units
offer a unique and innovative solution for those seeking a reliable and precise motion converter.

The linear speed of a rolling ring traverse unit is directly related to the contact angle between the rolling rings and the shaft. This feature allows for precise, controlled movement ideal for a wide range of applications requiring constant speed and unidirectional rotation of a shaft.

Their ability to deliver constant speed, reverse instantaneously, and provide finely variable speed and stroke length makes them a practical choice for various industrial applications.

10 Salient Features Of Rollring Traverse Unit

Rollring Traverse Unit is a versatile and efficient solution for converting rotary motion into linear reciprocating motion, and offers a range of unique features. The following are ten salient features of this innovative drive system:

The Rollring Traverse Unit provides unidirectional shaft rotation, ensuring smooth and stable operation.

The system maintains a constant speed of rotation irrespective of variations in load, ensuring predictable and reliable performance.

The traversal direction can be reversed instantaneously, providing a versatile and flexible solution for various applications.

The linear speed of the shaft can be finely adjusted by the flick of a lever, providing greater flexibility and precision.

The system enables finely variable stroke length, offering greater control and adaptability.

The Rollring Traverse Unit can traverse in reverse almost equal to the forward stroke, providing greater versatility and functionality.

The system has high mechanical efficiency, minimal energy losses, and low maintenance requirements.

The rolling rings minimized friction and wear, resulting in longer service life and reduced downtime.

The system provides high precision and accuracy, with minimal backlash and low tolerance.

The Rollring Traverse Unit is easy to install and operate, with simple and intuitive controls.

Rolling Ring for 20mm Diameter Shaft Model GP15
Suitable for shaft diameter 10mm, 15 mm, 20mm, 30mm, 40mm, 50mm, 60mm

Primary Application Areas

Rolling Ring Drives are used to construct a Traverse Unit, which has widespread application across various industries due to their versatile and high-performance capabilities. The Traverse Unit has become a preferred choice as it is an ideal solution to deliver controlled linear motion. Below are ten of many possible application areas in which the Rollring Traverse Unit is utilized:

1. Textile Industry

The Traverse Unit is used in the textile industry to ensure cloth movement.

2. Fiber Optics

In fiber optics, the Traverse Unit controls the movement of the fiber, ensuring that it remains smooth and friction-free.

3. Cable Manufacturing

Rolling Traverse Units are used in cable manufacturing to help move the wire in a straight line while laying the cable.

4. Food Processing

The food processing industry requires precise movement, and the Traverse Unit provides the necessary accuracy for moving food products.

5. Medical Equipment

In medical equipment, the Traverse Unit controls the movement of different parts.

6. Packaging Industry

Rolling Traverse Units are used in the packaging industry to control the packaging process.

7. Wire Industry

In the wire industry, Traverse Units are used to move the wire in a straight line while it is being wound.

8. Printing

Traverse Units are used in the printing industry to control the movement of the print head.

23 Types Of
Traverse Units Available For Selection.

These traverse units can be utilized for shaft diameters of 15mm, 20mm, 22mm, 25mm, 30mm, 40mm, 50mm, and 60mm. Additionally, they come in either three or four Rolling Ring configurations. Side thrust force ranges from 9kg to 100kg.

Rolling Ring Drive for 15mm Diameter Shaft

Rolling Ring Drive for 15mm Diameter Shaft

Traverse Unit Model GP3-15/GP15

  • Number of Rolling Rings: 3
  • Side thrust: 9 Kg / 90N
  • Maximum linear speed: 19 Meters/Minute
  • Top shaft speed: 2000 RPM
A Type Rolling Ring Drive for 20mm Diameter Shaft

Rolling Ring Drive for 20mm Diameter Shaft

Traverse Unit Model GP3-20/GP20

  • Number of Rolling Rings: 3
  • Side thrust: 16 Kg / 160N
  • Maximum linear speed: 27 Meters/Minute
  • Top shaft speed: 1500 RPM
A Type Rolling Ring Drives for 22mm Diameter Shaft

Rolling Ring Drives for 22mm Diameter Shaft

Traverse Unit Model GP3-22/GP22

  • Number of Rolling Rings: 3
  • Side thrust: 16 Kg / 160N
  • Maximum linear speed: 27 Meters/Minute
  • Top shaft speed: 1500 RPM
Rolling Ring Drive for 25mm Diameter Shaft Model GP3-25/GP25

Rolling Ring Drive for 25mm Diameter Shaft

Traverse Unit Model GP3-25/GP25

  • Number of Rolling Rings: 3
  • Side thrust: 26 Kg
  • Maximum linear speed: 24 Meters/Minute
  • Top shaft speed: 1000 RPM
A Type Rolling Ring Drive for 30mm Diameter Shaft

Rolling Ring Drive for 30mm Diameter Shaft

Traverse Unit Model GP3-30/GP30

  • Number of Rolling Rings: 3
  • Side thrust: 26 Kg
  • Maximum linear speed: 24 Meters/Minute
  • Top shaft speed: 1000 RPM
A Type Rolling Ring Drive for 40mm Diameter Shaft

Rolling Ring Drive for 40mm Diameter Shaft

Traverse Unit Model GP3-40/GP40

  • Number of Rolling Rings: 3
  • Side thrust: 42 Kg
  • Maximum linear speed: 23.25 Meters/Minute
  • Top shaft speed: 750 RPM
Rolling Ring Drive for 50mm Diameter Shaft Model GP3-50/ GP50

Rolling Ring Drive for 50mm Diameter Shaft

Traverse Unit Model GP3-50/ GP50

  • Number of Rolling Rings: 3
  • Side thrust: 68 Kg
  • Maximum linear speed: 18 Meters/Minute
  • Top shaft speed: 500 RPM
Rolling Ring Drive for 60mm Diameter Shaft Model GP3-60/ GP60

Rolling Ring Drive for 60mm Diameter Shaft

Traverse Unit Model GP3-60/ GP60

  • Number of Rolling Rings: 3
  • Side thrust: 100 Kg
  • Maximum linear speed: 17.5 Meters/Minute
  • Top shaft speed: 350 RPM
Rolling Ring for 15mm Diameter Shaft Model GP15 guide wheel

Rolling Ring Drive for 15mm Diameter Shaft with Guide Wheel

Traverse Unit Model GP3-15/GP15 Guide Wheel

  • Number of Rolling Rings: 3
  • Side thrust: 9 Kg / 90N
  • Maximum linear speed: 19 Meters/Minute
  • Top shaft speed: 2000 RPM
Rolling Ring Drive for 20mm Diameter Shaft Model GP20 guide wheel

Rolling Ring Drive for 20mm Diameter Shaft with Guide Wheel

Traverse Unit Model GP3-20/GP20 Guide Wheel

  • Number of Rolling Rings: 3
  • Side thrust: 16 Kg / 160N
  • Maximum linear speed: 27 Meters/Minute
  • Top shaft speed: 1500 RPM
Rolling Ring Drive for 30mm Diameter Shaft Model GP3-30/GP30 guide wheel

Rolling Ring Drive for 30mm Diameter Shaft with Guide Wheel

Traverse Unit Model GP3-30/GP30 Guide Wheel

  • Number of Rolling Rings: 3
  • Side thrust: 26 Kg
  • Maximum linear speed: 24 Meters/Minute
  • Top shaft speed: 1000 RPM
Rolling Ring Drive for 15mm Diameter Shaft Model GP4-15 4JPX15

Rolling Ring Drive for 15mm Diameter Shaft

Traverse Unit Model GP4-15 4JPX15

  • Number of Rolling Rings: 4
  • Side thrust: 20 Kg
  • Maximum linear speed: 19 Meters/Minute
  • Top shaft speed: 2000 RPM
GP4 Type Rolling Ring Drive for 20mm Diameter Shaft

Rolling Ring Drive for 20mm Diameter Shaft

Traverse Unit Model GP4-20 4JPX20

  • Number of Rolling Rings: 4
  • Side thrust: 32 Kg
  • Maximum linear speed: 27 Meters/Minute
  • Top shaft speed: 1500 RPM
Rolling Ring Drive for 30mm Diameter Shaft Model GP4-30 4JPX30

Rolling Ring Drive for 30mm Diameter Shaft

Traverse Unit Model GP4-30 4JPX30

  • Number of Rolling Rings: 4
  • Side thrust: 52 Kg
  • Maximum linear speed: 24 Meters/Minute
  • Top shaft speed: 1000 RPM
Rolling Ring Drive for 40mm Diameter Shaft Model GP4-40 4JPX40

Rolling Ring Drive for 40mm Diameter Shaft with Guide Wheel

Traverse Unit Model GP4-40/4JPX40 Guide Wheel

  • Number of Rolling Rings: 4
  • Side thrust: 84 Kg
  • Maximum linear speed: 23.25 Meters/Minute
  • Top shaft speed: 750 RPM
Rolling Ring Drive for 50mm Diameter Shaft Model GP4-50 4JPX50

Rolling Ring Drive for 50mm Diameter Shaft with Guide Wheel

Traverse Unit Model GP4-50/4JPX50 Guide Wheel

  • Number of Rolling Rings: 4
  • Side thrust: 136 Kg
  • Maximum linear speed: 18 Meters/Minute
  • Top shaft speed: 500 RPM
Rolling Ring Drive for 60mm Diameter Shaft Model GP4-60 4JPX60

Rolling Ring Drive for 60mm Diameter Shaft with Guide Wheel

Traverse Unit Model GP4-60/4JPX60 Guide Wheel

  • Number of Rolling Rings: 4
  • Side thrust: 200 Kg
  • Maximum linear speed: 17.5 Meters/Minute
  • Top shaft speed: 350 RPM
Similar To Uhing Rolling Ring for 15mm Diameter Shaft

Rolling Ring for 15mm Diameter Shaft

Traverse Unit Model RG3-15-2MCRF/PX15

  • Number of Rolling Rings: 3
  • Side thrust: 9 Kg / 90N
  • Maximum linear speed: 19 Meters/Minute
  • Top shaft speed: 2000 RPM
Rolling Ring Drive Similar To Uhing RG3-20-2mcrf for 20mm Diameter Shaft

Rolling Ring for 20mm Diameter Shaft

Traverse Unit Model RG3-20-2MCRF/PX20

  • Number of Rolling Rings: 3
  • Side thrust: 16 Kg
  • Maximum linear speed: 27 Meters/Minute
  • Top shaft speed: 1500 RPM
Rolling Ring Drive Similar To Uhing RG3-30-2mcrf for 30mm Diameter Shaft

Rolling Ring for 30mm Diameter Shaft

Traverse Unit Model RG3-30-2MCRF/PX30

  • Number of Rolling Rings: 3
  • Side thrust: 26 Kg
  • Maximum linear speed: 24 Meters/Minute
  • Top shaft speed: 1000 RPM
Rolling Ring Drive Similar To Uhing RG3-40-2mcrf for 40mm Diameter Shaft

Rolling Ring for 40mm Diameter Shaft

Traverse Unit Model RG3-40-2MCRF/PX40

  • Number of Rolling Rings: 3
  • Side thrust: 42 Kg
  • Maximum linear speed: 23.25 Meters/Minute
  • Top shaft speed: 750 RPM
Rolling Ring Drive Similar To Uhing RG3-50-2mcrf for 50mm Diameter Shaft

Rolling Ring for 50mm Diameter Shaft

Traverse Unit Model RG3-50-2MCRF/PX50

  • Number of Rolling Rings: 3
  • Side thrust: 68 Kg
  • Maximum linear speed: 18 Meters/Minute
  • Top shaft speed: 500 RPM
Rolling Ring Drive Similar To Uhing RG3-60-2mcrf for 60mm Diameter Shaft

Rolling Ring for 60mm Diameter Shaft

Traverse Unit Model RG3-60-2MCRF/PX60

  • Number of Rolling Rings: 3
  • Side thrust: 100 Kg
  • Maximum linear speed: 17.5 Meters/Minute
  • Top shaft speed: 350 RPM

Didn't find the right one?

If you were unable to find the Rolling Ring Drives that meet your requirements, we are committed to providing you with a 24-hour expert service. just a call away.
