Technical specification:
Usage： this machine is suitable for square or round paper drums and cartons of plum packaging
Main accessories brand: all electrical appliance bearings using famous brands;
- Motor: Constant speed AC motor
- Controller: Japan Yaskawa 415V inverter;
- Programmable design controller: Delta;
- Electrical appliances: all electrical appliances adopt the Chint and Shilin brands;
- Bearing: Harbin; NSK;
Main specifications and performance:
- Applicable outer diameter: Ф2mm-Ф6.0mm;
- Height of packaging and conveying platform: 350mm;
- Outer dia: 500mm, high 400-500mm, weight 75-100kg.
The equipment composition specifications
| Specifications | Details |
|---|---|
| Adaptable wire diameter | MaxФ2-Ф6 mm (soft wire). |
| Adapt line speed | adapt to speed 300 m/min. |
| Power | 4KW AC motor, three-phase 380V voltage. |
| Molding pattern | overlapping plum blossom shape. |
| Vibration device | by a 1/2hp gear motor, control the vibration platform and improve the amount of cable barrel; the cable through the vibration will be more encrypted, reducing transportation loss. |
| Adapt to falling barrel | outer barrel inner diameter 575mm¡Á inner barrel outer diameter 300mm¡Á height 585mm. (or other non-standard sizes) |
| Meter meter forecast function | and meter meter to automatic barrel change, storage line, manual waste line elimination control. |
| Threading method | Can achieve rapid stringing. |
| Suitable for | round wire plum blossom type into barrels; it is easy to put the line in the post-sequence such as cutting and peeling, etc., will not be knotted, and adapts to the highest cutting speed of 10m/s. |
| Weight | 2000kg. |
| Operation direction | Customized according to customer requirements. |
| Machine color | Off-white. |
Ф500 Plum blossom barrel receiver auxiliary parts:
Match additional inlet guide frame steering mechanism.
