Cable Length Meter Counter For 1-45mm Or 1-75mm Cable

Cable Length Meter Counter Description

the cable length meter counter, also often called a “wire length meter counter” or “digital length counter meter”, is a device that accurately measures the length of linear materials (such as cables, optical cables, ropes, pipes, etc.) through mechanical contact. It plays a vital role in cable production, laying and acceptance.

Length Counter Meter Parameter

Length Meter Counter Operating Principle

Contact and Rolling: A measuring wheel (caterpillar wheel) with a precisely known circumference is pressed against the cable surface with a specific amount of pressure.

Synchronized Rotation: As the cable moves, it drives the measuring wheel to rotate in sync, with no (or negligible) slippage between them.

Counting and Conversion: The axle of the measuring wheel is connected to a high-precision encoder or a mechanical counter. For each full rotation of the wheel, the counter records a fixed number of pulses.

Q＆A About Cable Length Meter Counter

1. What Is The Measuring Range Of The Wire Meter Counter For The Winding Machine?

Ans: The measuring range of the meter can be customized from 1-45mm

2. How Fast Can The Digital Length Counter Meter The Number Of Meters?

Ans: The meter can count up to 300m/min

3. Does The Wire Counter Meter With A Display For Meter Readings?

Ans: The meter has an electronic digital display for an accurate reading.

4. Can The Measurement Method Of The Meter Be Customized?

Ans: The meter can be customized to accommodate the encoder or induction measuring method.
